- Artikel-Nr.: APIX6T
In this fast-paced market, the AlphaPix 6T Touring family consistently keep ahead of the game by delivering top quality images with the latest high-resolution temporary outdoor LED display. The AlphaPix 6T uses high-brightness, black-faced, square LEDs with UV coatings in a robust and lightweight die-cast aluminium housing. The frame and fast interlocking system creates a seamless image with minimal setup time. To deliver the perfect image, the AlphaPix 6T series features a high refresh-rate, advanced greyscale properties and automatic image correction along with a 140° viewing angle.
Main features:
- Outdoor (IP65/IP54) die-cast aluminium housing for temporary outdoor installation.
- Gapless panel joins for seamless image
- High-brightness square LEDs with UV coating
- Flicker-free on camera
- High-performance video reproduction at every level of brightness
- 140° viewing angle
- CE and EMC certified by TUV
TECHNICAL SPECIFICATIONS
VIDEO
- LED source: SMD 3535 high-power FC black face
- Pixel pitch: 6.6mm / 0.26''
- Panel resolution: 96x108pixels
- Module resolution: 48x36pixels
- Luminous flux: 5.500nit
- Grayscale: 16 bit
- Refresh rate ≥: 1.920Hz
- Drive Mode: 1/6 scan, constant current
- Vertical viewing angle: 70°
- Horizontal viewing angle: 140°
- LED density: 22.500LED/sqm
- Dead Pixel Ratio: <0,002
- LED avg life span: 100.000
ELECTRICAL
- Power input/output: Seetronic powerCON
- Power supply: AC 110/230 V 50/60 Hz
- Max power consumption (panel): 415W
- Avg power consumption (panel): 139W
- Max power consumption (sqm): 900W
- Avg power consumption (sqm): 300W
- Standby power consumption (pannello): 22,5W
- Max rated current/panel:: AC 220 V / 1,88 A
- Max power output: 3modules
- Working temperature: -10 ~ +40°C
- Working humidity: 10-90%
CONTROL
- Control protocol: Novastar
- Signal input: waterproof Seetronic RJ45
- Signal output: waterproof Seetronic RJ45
MECHANICS
- Module size (WxH): 320x240mm / 12.6''x9.45''
- Panel size(WxHxD): 640x720x100mm / 25.2''x28.35''x3.94''
- Vertical hanging system: built-in aliscaf clamp support
- Cooling: forced air with low noise fan, user-definable levels
- Connection: seamless locking system
- Body: die-cast aluminium housing
- Color: black
- IP rating: IP65 / IP54
- Panel weight: 13,5kg / 29.76lbs
- Weight per square meter: 30kg / 66.14lbs
- Hanging Panel Quantity ≤: 15
- Compliant Standard: CE
