PL EclFresnel JrPTW, 130W 6-Farb-LED, 2800K-10000K, P.O., schwarz

EclFresnel JrPTW is an advanced LED replacement of traditional 650W Fresnel lamps, featuring 6 colour mixing delivering high precision reproduction of the white spectrum from 2.800 K to 10.000 K with high CRI and an extensive colour reproduction. The optical system harnesses the power of a 130W custom LED with 6 colours to create an even projection, beautiful colours and precise white, with added ability to apply +/- green and magenta correction to match other sources of light. Featuring HD dimming and tuning from 2.800 K to 10.000 K version with external battery capabilities, the EclFresnel JrPTW delivers the performance and quality of output demanded from this level of luminaire.

Main features:

• Tunable white 2.800 K - 10.000 K with high CRI and extensive colour mixing
• +/- green and magenta white tuning
• Silent operation for studio and stage use
• Battery ready, compatible with industry standard external batteries (optional)

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 130W 6 colour custom LEDs source (red, orange, cyan, royal blue, green, lime)
• CCT: 2.800 K - 10.000
• Luminous flux: (16°) 1'610 lm - (80°) 2'952lm @full
• Lux: (16°) 709 lx - (80°) 145lx @5 m full
• CRI: 91 @3.200 K; 92 @5.600 K
• R9: 91 @3.200 K; 92 @5.600 K
• TLCI: 86 @5.600 K
• TM30 Rf: 88 @3.200 K; 86 @5.600 K
• TM30 Rg: 106 @3.200 K; 104 @5.600 K
• Source life expectancy: > 50.000 h

OPTICS

• Zoom: 16° - 80° manual
• Lens diameter: 6'' - 150mm / 0.24''
• Lens type: fresnel zoom lens

COLOUR SYSTEM

• Colour mixing: tunable white + colour
• CCT: CCT control, + / - green correction, tungsten emulation
• White presets: 2.800 K - 10.000K
• Colour wheel: virtual colour wheel with macros
• Macros: several pre-built macros with adjustable speed

DYNAMIC EFFECTS

• Static mode: selection of static colour
• Manual mode: manual adjustment of intensity, CT, colour correction from knob
• Auto mode: built-in programs with execution speed adjustment
• Special features: linear crossfade channel from any white to any colour; virtual CTO on colours

BODY

• Hardware on-board: filter frame, 8 doors barndoor, spigot
• Pan angle: 360° with manual regulation
• Tilt angle: 340° with manual regulation
• Body: sturdy die-cast aluminium body
• Body colour: black
• Other: Spigot 28 mm

CONTROL

• Protocols: DMX512, RDM, rotatory knob
• DMX channels: 1 / 2 / 5 - 1 / 5 - 2 / 7 / 9 / 12 / 13 / 16 / 19 / 21channel
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
• Other: 16bit control of dimmer and colour

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 - 30 Hz, electronic
• LED Control: flicker free frequency with adjustable PWM
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 106W
• Output (at 230V): 23 units on a single power line
• Power factor: >0,95

BATTERY

• Battery: 29,6V 4400 mAh external battery (optional ECLFRSJBP4)
• Re-charge connection: connection for external battery throught XLR 4p
• Other: Voltage range: 22,4V-33,6V

PHYSICAL

• IP rating: 20
• Cooling: combination of heat pipe cooling system and low noise fan
• Suspension and fixing: bracket for hanging and positioning
• Signal connection: Amphenol XLR 5p IN/OUT connectors
• Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
• Dimensions (WxHxD): 298x496x260mm / 11.73''x19.53''x10.24''
• Weight: 7,5kg / 16.53lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM
