PL EclFresnel 2KTU, 500W, 3200K, M.O., schwarz

EclFresnel 2K is the LED replacement for a standard tungsten 2.000W Fresnel. Featuring the output characteristics of a traditional Fresnel but with beam control, functional barn doors and a power source that focuses on outstanding colour rendition. The EclFresnel 2K adds all the advantages of LED to the Fresnel.

Main features:

• TU (3.200 K) and DY (5.600 K) versions available both with HD dimming
• Fresnel lens with 16° to 64° zoom range
• Silent operation for studio and stage use

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 500W high-power white LED
• CCT: (TU) 3.200 K - (DY) 5.600
• Luminous flux: (TU) (16°) 20'256 lm; (64°) 26'126lm @full
• Luminous flux: (DY) (16°) 26'255 lm; (64°) 32'428 lm @ full
• Lux: (TU) (16°) 9'047 lx - (64°) 1'770lx @5 m full
• Lux: (DY) (16°) 11'975 lx - (64°) 2'306lx @5 m full
• CRI: (TU) >94; (DY) >91
• R9: (TU) >73; (DY) >80
• TLCI: (TU) >93; (DY) >93
• TM30 Rf: (TU) >92; (DY) >88
• TM30 Rg: (TU) <103; (DY) <104
• Source life expectancy: > 50.000 h

OPTICS

• Zoom: 16° - 64° manual
• Lens diameter: 250mm / 9.84''
• Lens type: Fresnel zoom lens
• Other: spigot, barndoor and gel frame included

COLOUR SYSTEM

• Colour mixing: warm white
• Macros: several pre-built macros with adjustable speed

DYNAMIC EFFECTS

• Static mode: selection of static dimmer
• Manual mode: manual adjust of dimmer throught menu and knob
• Auto mode: built-in programs with execution speed adjustment

BODY

• Hardware on-board: filter frame, 8 doors barndoor, spigot
• Pan angle: (for pole operated version) 360° with manual regulation
• Tilt angle: (for pole operated version) 180° with manual regulation
• Body: sturdy die-cast aluminium body
• Body colour: black, white finishing available
• Other: Spigot 28 mm

CONTROL

• Protocols: DMX512, RDM, rotatory knob
• DMX channels: 1 / 2 - 1 / 2 - 2 / 3 / 5channel
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
• Master/Slave: for synchronised operation of more units linked in a chain
• Other: 16bit control of dimmer

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: selectable dimming modes available
• Strobe / shutter: 1 - 30 Hz, electronic
• Operating temperature: -10° ~ +45°
• LED Control: flicker free frequency with adjustable PWM
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 500W
• Output (at 230V): 4 units on a single power line
• Power factor: >0,96

PHYSICAL

• IP rating: 20
• Cooling: combination of heat pipe cooling system and low noise fan
• Suspension and fixing: bracket for hanging and positioning
• Signal connection: Amphenol XLR 5p IN/OUT connectors
• Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
• Dimensions (WxHxD): 421x537x456mm / 16.57''x21.14''x17.95''
• Dimensions with PO system (WxHxD): 401x691x456mm / 15.79''x27.2''x17.95''
• Weight: 17,2kg / 37.92lbs
• Weight with PO system: 18kg / 39.68lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM
