PL SunRise 2IP, LED-Blinder, 2x75W, IP65

Sunrise 2IP is an IP rated and convection cooled modular 2x1 LED Blinder, designed to be a perfect touring solution to replace classic halogen fixtures of any sizes.The fixture is designed with on-board, fast-locking mechanism in order to combine multiple units together and using them as brick, turning the Sunrise 2IP into a 4x1 or a 2x2 blinder easily. The Sunrise 2IP is equipped with 2x75 W COB Warm White LEDs pixel controlled and its optical system is capable to output the same performance and beam angle of the fluorescent bulbs, including dimmer ramp with red-shift.

Main features:

• 2x75W Warm White LED with Amber backlight for tungsten simulation
• Modular fast-locking assembly to combine multiple units together
• IP rated and convection cooled

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 2 x 8 W Amber + 2 x 75W Warm White LEDs
• CCT: 2.700
• Luminous flux: 10'088lm @full
• Lux: 1'076lx @3 m full
• Lux: 387lx @5 m full
• CRI: > 93
• TLCI: > 91
• TM30 Rf: > 91
• TM30 Rg: > 97
• Source life expectancy: > 70.000 h

OPTICS

• Beam angle: 60°
• Field angle: 100°
• Lens type: parabolic reflector

DYNAMIC EFFECTS

• Static mode: selection of static dimmer
• Manual mode: manual adjustment of dimmer and strobe
• Auto mode: built-in programs with execution speed adjustment
• Special features: tungsten emulation activation

BODY

• Body: sturdy die-cast aluminium body
• Body colour: RAL 9004
• Other: on board mechanics for modular assembly of multiple fixtures

CONTROL

• Protocols: DMX512, RDM
• DMX channels: 1 / 2 / 6 / 12channel
• Pixel control: pixel2pixel control
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
• Master/Slave: for synchronised operation of more units linked in a chain
• Other: 16bit control of dimmer

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 ~ 30 Hz, electronic
• Operating temperature: -10° ~ +45°
• LED Control: flicker free frequency with adjustable PWM
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 160W
• Output (at 230V): 16 units on a single power line
• Power factor: > 0,94

PHYSICAL

• IP rating: 65 for temporary outdoor application, not for fixed installations
• IK rating: 08
• Cooling: passive cooling and fan-free
• Suspension and fixing: bracket for truss rigging and hardware for connection of more units
• Signal connection: Seetronic XLR 5p IN/OUT connectors
• Power connection: Seetronic powerCON TRUE IP65 IN/OUT
• Dimensions (WxHxD): 432x230x102mm / 17.01''x9.06''x4.02''
• Weight: 7,6kg / 16.76lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM
