PL Solar 48Q, 48x10W RGBW, IP65, W-DMX, schwarz
inkl. MwSt. zzgl. Versandkosten
Wenn verfügbar beim Hersteller, Lieferzeit ca. 1-3 Werktage.
* Die aktuelle Lieferzeit kann gerne vorab angefragt werden. Jetzt anfragen.
- Artikel-Nr.: SOLAR48Q
Solar 48Q is a compact fan-free outdoor wash light featuring an outstanding brightness of 22'760 lumens. Equipped with 48x10 W RGBW full-colour LEDs all delivering superior colour mixing. Featuring a slimline styling, multiple interchangeable optics through magnets, asymmetrical filters which combined, make the Solar 48Q an incredibly flexible device for indoor and outdoor use. Whilst highly-powerful, the Solar 48Q is also completely silent.
Main features:
- 48x10W RGBW / FC LED delivering 22'760 lumens
- Compact form factor and fan-free
- Wireless DMX on-board
TECHNICAL SPECIFICATIONS
LIGHT SOURCE
- Source: 48x10W RGBW / FC LEDs
- Luminous flux: 28'213lm @full
- Lux: (25°) 4'638lx @5 m full
- Lux: (45°) 986lx @5 m full
- Source life expectancy: > 50.000 h
OPTICS
- Beam angle: 25°
- Additional optics: 10° / 15° / 45° / 40° filter / 60° filter/ 10x60° filter / 30x60° filter
- Other: magnetic 40° filter included, barn door not included
COLOUR SYSTEM
- Colour mixing: RGBW / FC
- CCT: CCT control through dedicated DMX channel
- Colour wheel: virtual colour wheel with macros
- Macros: several pre-built macros with adjustable speed
DYNAMIC EFFECTS
- FX generator: section effect with 4 horizontal individually select and control sections
- Static mode: selection of static colour
- Manual mode: manual adjustment of colour
- Auto mode: built-in programs with execution speed adjustment
BODY
- Hardware on-board: magnetic filter frame with 40° filter
- Tilt angle: 0 - 150° with manual regulation
- Body: sturdy die-cast aluminium body
- Body colour: black
CONTROL
- Protocols: DMX512, RDM, W-DMX
- DMX channels: 5 / 7 / 10 / 17 / 22channel
- Wireless Control: included, LumenRadio Timo Fx DMX/RDM compatible with both CRMX (Lumen Radio) and W-DMX (Wireless DMX)
- RDM: RDM for remote monitoring and settings
- Display: Graphic User Interface
- Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
- Master/Slave: for synchronised operation of more units linked in a chain
ELECTRONICS
- Dimmer: linear 0 ~ 100% electronic dimmer
- Dimmer curves: 4 selectable dimming modes available
- Strobe / shutter: 1 - 30 Hz, electronic
- Display battery: self-charging battery backup
- Operating temperature: -20° ~ +45°
- LED Control: flicker free frequency with adjustable PWM
- Selectable PWM: 600 ~ 25.000 Hz
ELECTRICAL
- Mains power supply: 100-240V - 50/60Hz
- Max power consumption: 520W
- Output (at 230V): 5 units on a single power line
- Power factor: > 0,95
PHYSICAL
- IP rating: 65 for temporary outdoor application, not for fixed installations
- Cooling: passive cooling and fan-free
- Suspension and fixing: hanging bracket for floor positioning with "Quick-Lock" system
- Signal connection: Seetronic XLR 5p IN/OUT connectors
- Data connection: W-DMX receiver
- Power connection: Seetronic powerCON waterproof IN/OUT connectors
- Dimensions (WxHxD): 563x314x93mm / 22.17''x12.36''x3.66''
- Weight: 12,9kg / 28.44lbs
CERTIFICATIONS / APPROVALS
- Certifications / Approvals: CE, UKCA, RCM
