PL Solar 27Q, 27x10W RGBW, IP65, W-DMX, schwarz
inkl. MwSt. zzgl. Versandkosten
Wenn verfügbar beim Hersteller, Lieferzeit ca. 1-3 Werktage.
* Die aktuelle Lieferzeit kann gerne vorab angefragt werden. Jetzt anfragen.
- Artikel-Nr.: SOLAR27Q
Solar 27Q is a compact fan-free outdoor wash light featuring an outstanding brightness of 10'832 lumens. Equipped with 27x10W RGBW/FC LEDs, delivering superior colour mixing. Featuring a slim size as well as the multiple interchangeable optics through magnets, including asymmetrical filters which, all together, make the Solar 27Q an incredibly flexible device for indoor use and outdoor. Whilst highly-powerful, the Solar 27Q also benefits from being silent.
Main features:
- 27x10W RGBW/FC LEDs, delivering 10'832 lumens
- Compact form factor and fan-free
- Wireless DMX on-board
TECHNICAL SPECIFICATIONS
LIGHT SOURCE
- Source: 27x10W RGBW / FC LEDs
- Luminous flux: @FULL 10'832 lm - with included filter 6'987lm
- Lux: @FULL (25°) 6'340 lx - with included filter 1'027lx @3 m full
- Lux: @FULL (25°) 2.282 lx - with included filter 370lx @5 m full
- CRI: 71,8
- Source life expectancy: > 50.000 h
OPTICS
- Beam angle: 25°
- Additional optics: 10° / 15° / 45° / 40° filter /60° filter/ 10x60° filter / 30x60° filter
- Other: magnetic 40° filter included , barn door not included
COLOUR SYSTEM
- Colour mixing: RGBW / FC
- CCT: CCT control through dedicated DMX channel
- Colour wheel: virtual colour wheel with macros
DYNAMIC EFFECTS
- FX generator: section effect with 3 horizontal individually select and control sections
- Static mode: selection of static colour
- Manual mode: manual adjustment of colour
- Auto mode: built-in programs with execution speed adjustment
BODY
- Hardware on-board: magnetic filter frame with 40° filter
- Tilt angle: 0 - 150° with manual regulation
- Body: sturdy die-cast aluminium body
- Body colour: black
CONTROL
- Protocols: DMX512, RDM, W-DMX
- DMX channels: 5 / 7 / 10 / 13 / 17channel
- Wireless Control: included, LumenRadio Timo Fx DMX/RDM compatible with both CRMX (Lumen Radio) and W-DMX (Wireless DMX)
- RDM: RDM for remote monitoring and settings
- Display: Graphic User Interface
- Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
- Master/Slave: for synchronised operation of more units linked in a chain
ELECTRONICS
- Dimmer: linear 0 ~ 100% electronic dimmer
- Dimmer curves: selectable dimming modes available
- Display battery: self-charging battery backup
- Operating temperature: -20° ~ +50°
- LED Control: flicker free frequency with adjustable PWM
- Selectable PWM: 600 ~ 25.000 Hz
ELECTRICAL
- Mains power supply: 100-240V - 50/60Hz
- Max power consumption: 268W
- Max power consumption (at 120V): 275W
- Output (at 230V): 9 units on a single power line
- Output (at 120V): 5 units on a single power line
- Power factor: 0,994
PHYSICAL
- IP rating: 65 for temporary outdoor application, not for fixed installations
- Cooling: passive cooling and fan-free
- Suspension and fixing: hanging bracket for floor positioning with "Quick-Lock" system
- Signal connection: Seetronic XLR 5p IN/OUT connectors
- Data connection: W-DMX receiver
- Power connection: Seetronic powerCON waterproof IN/OUT connectors
- Dimensions (WxHxD): 454x269x83mm / 17.87''x10.59''x3.27''
- Weight: 9kg / 19.84lbs
CERTIFICATIONS / APPROVALS
- Certifications / Approvals: CE, UKCA, RCM
Es sind leider keine Geräte verfügbar.
Es kann vorkommen, dass in unserem Lager noch gebrauchte Geräte vorhanden sind. Fragen Sie gerne über unsere Service-Hotline +49 871 40875521 oder per Email info@lights-whatever.de bei uns nach. Wir helfen Ihnen gerne weiter!
