PL PanoramaIP AirBeam, IP65, 440W Osram Sirius HRI, 2° 2 x im Case

PanoramaIP AirBeam is a stunning IP65 moving beam light which delivers an unbelievable bright, fat 2° beam ideal for an outdoor searchlight and big air look. Designed to make a statement, the PanoramaIP AirBeam can truly make an event stand out or fill a large outdoor space with spectacular beams.

Main features:

• IP65 rated for temporary outdoor application, not for fixed installation
• Powerful 440W S Osram HTI lamp combined with 167 mm HD front lens for bright 2° beam
• Extensive set of effects including linear CMY mixing, rotating gobo wheel, static gobo wheel, circular and linear prisms, linear frost and focus

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 440W S Osram Sirius HRI
• CCT: 7.000
• Luminous flux: 12'457lm
• Lux: 1'270'259lx @5 m full
• Lux: 317'565lx @10 m
• CRI: 80
• Source life expectancy: 1.500 h

OPTICS

• Beam angle: 2°
• Lens diameter: 167mm / 6.57''
• Lens type: high-quality glass lens optics
• Focus: motorised with auto-focus

COLOUR SYSTEM

• Colour mixing: CMY colour system on 3 gradually fading colour wheels
• CCT: on wheel 2.500 K and 3.200 K + CTB
• Colour wheel: 13 dichroic filters on 3 independent colour wheels

DYNAMIC EFFECTS

• Rotating gobos: 9 rotating gobos + open, interchangeable, indexing
• Gobo size: outer: 15,8 mm - image: 9 mm - thickness: 0,3 mm
• Fixed gobos: 15 fixed gobos + open
• FX generator: prisms overlap for spectacular aerial effects
• Circular prism: 16f with bi-directional rotation, indexing
• Linear prism: 6f with bi-directional rotation, indexing
• Frost: linear 0 - 100% frost filter

BODY

• Pan angle: 630° - 540°
• Tilt angle: 230°
• Pan/Tilt resolution: bit 16-bit
• Feedback: automatic repositioning after accidental movement
• Body: aluminium structure with high-resistance polycarbonate cover
• Body colour: black

CONTROL

• Protocols: DMX512, RDM, Art-Net, W-DMX
• DMX channels: 19 / 22 / 28channel
• Wireless Control: included, wireless solution receiver
• RDM: RDM for remote monitoring and settings
• Display: LCD high resolution colour display with autoflip
• Firmware upgrade: via menu with internal memory or via USB - DMX interface (UPBOX2) not included
• Hibernation: power safe mode when lost DMX

ELECTRONICS

• Dimmer: linear 0 ~ 100% mechanical dimmer
• Strobe / shutter: 1 - 28 flash(s), mechanical
• Operating temperature: -20° ~ +40°

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 522W
• Max power consumption (at 120V): 522W

PHYSICAL

• IP rating: 65 for temporary outdoor application, not for fixed installations
• Cooling: active, silent operation
• Suspension and fixing: any position with quick-lock omega brackets
• Signal connection: Seetronic XLR 5p IN/OUT connectors
• Data connection: Art-Net RJ45 IN/OUT
• Power connection: Neutrik powerCON TRUE1 IN connector
• Dimensions (WxHxD): 441x746x326mm / 17.36''x29.37''x12.83''
• Weight: 39kg / 85.98lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM
