PL Jet Spot2, 150W LED, 20°, schwarz

Jet Spot2 is a LED spot luminaire designed to deliver a stunning light level for its size and price. Ideal both for installation and for rental, the Jet Spot2 focuses on maximising the light output from its LED source to deliver a crisp, even beam from a compact size.

Main features:

• Ultra-efficient 150W 8.000 K white LED source
• Fixed 20° beam angle
• Extensive effects including one colour wheel, rotating gobo wheel, static gobo wheel, prism and focus

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 150W high-power white LED
• CCT: 8.000
• Luminous flux: 7'400lm
• Lux: 8'900lx @3 m
• Lux: 810lx @10 m
• CRI: 78
• Source life expectancy: > 50.000 h

OPTICS

• Beam angle: 20°
• Focus: motorised

COLOUR SYSTEM

• Colour wheel: 8 colour filters

DYNAMIC EFFECTS

• Rotating gobos: 7 rotating gobos + open, interchangeable, indexing
• Gobo size: outer: 24,2 mm - image: 20 mm - thickness: 0,3 mm
• Fixed gobos: 8 fixed gobos + open
• Circular prism: 3f with bi-directional rotation, indexing
• Auto mode: built-in programs with execution speed adjustment

BODY

• Pan angle: 540°
• Tilt angle: 270°
• Pan/Tilt resolution: bit 8 / 16-bit
• Feedback: automatic repositioning after accidental movement
• Body: aluminium structure with high-resistance polycarbonate cover
• Body colour: black, white finishing available

CONTROL

• Protocols: DMX512, RDM
• DMX channels: 12 / 15channel
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
• Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Strobe / shutter: 1 - 30 Hz, electronic
• Operating temperature: -10° ~ +45°

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 225W
• Max power consumption (at 120V): 226W
• Output (at 230V): 16 units on a single power line
• Output (at 120V): 8 units on a single power line

PHYSICAL

• IP rating: 20
• Suspension and fixing: any position with quick-lock omega brackets
• Signal connection: XLR 3p + 5p IN/OUT connectors
• Power connection: Seetronic powerCON IN/OUT connectors
• Dimensions (WxHxD): 308x436x230mm / 12.13''x17.17''x9.06''
• Weight: 13,7kg / 30.2lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM

Es sind leider keine Geräte verfügbar.

Es kann vorkommen, dass in unserem Lager noch gebrauchte Geräte vorhanden sind. Fragen Sie gerne über unsere Service-Hotline +49 871 40875521 oder per Email info@lights-whatever.de bei uns nach. Wir helfen Ihnen gerne weiter!
