PL Pixie Beam, 60W RGBW, 4,5°

Pixie Beam is a fast, bright and compact moving LED beam luminaire. Some looks are all about scale. The Pixie Beam takes this idea to a different level featuring incredible speed and infinite rotation of both pan and tilt.

Main features:

• Single 60W Osram Ostar RGBW LED with 100 mm lens delivers a bright, consistent 4,5° beam
• Compact, lightweight and incredibly fast - the Pixie Beam moves with 'moving mirror' speed
• Infinite pan and tilt rotation for additional effects

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 60W RGBW Osram Ostar LEDs
• Lux: 11'120lx @3 m full
• Source life expectancy: > 50.000 h

OPTICS

• Beam angle: 4,5°
• Lens diameter: 100mm / 3.94''

COLOUR SYSTEM

• Colour mixing: RGBW / FC
• CCT: CCT control through dedicated DMX channel
• White presets: 2.000 K ~ 8.000K
• Colour wheel: virtual colour wheel with macros

BODY

• Pan angle: ° with 360° continuous rotation
• Tilt angle: ° with 360° continuous rotation
• Pan/Tilt resolution: bit 8 / 16-bit
• Feedback: automatic repositioning after accidental movement
• Body: aluminium structure with high-resistance polycarbonate cover
• Body colour: black

CONTROL

• Protocols: DMX512, RDM
• DMX channels: 14 / 16 / 18channel
• RDM: RDM for remote monitoring and settings
• Display: Graphic User Interface
• Firmware upgrade: yes, via USB - DMX interface (UPBOX2) not included
• Hibernation: power safe mode when lost DMX
• Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Strobe / shutter: 1 - 25 Hz, electronic
• Operating temperature: -10° ~ +45°
• LED Control: flicker free operation

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 82W
• Max power consumption (at 120V): 82W
• Output (at 230V): 15 units on a single power line

PHYSICAL

• IP rating: 20
• Cooling: active, silent operation
• Suspension and fixing: any position with quick-lock omega brackets
• Signal connection: Amphenol XLR 5p IN/OUT connectors
• Power connection: Neutrik powerCON IN/OUT connectors
• Dimensions (WxHxD): 208x300x144mm / 8.19''x11.81''x5.67''
• Weight: 4kg / 8.82lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM
