PL DisplayCob WW, 45W, 3200K, IP20, schwarz

DisplayCob WW is the compact version of the popular StudioCob WW - perfect for an installation or indoor venues. DisplayCob WW employs a 45 W COB LED source tungsten white 3.200 K, combined with a special parabolic reflector built in aluminium which develops an extremely bright and homogeneous output of 96 CRI and interchangeable lens systems to switch from 60° (incl.) to 30° (incl.) and 15° (opt.).

Main features:

• Compact LED PAR with high CRI 45W Warm White COB source
• HD dimming and an extensive and even colour palette
• Flexible lens options of 15° - 30° - 60° and functional barn doors

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 45W White COB LED
• CCT: 3.200
• Luminous flux: (30°) 2'171 - (60°) 2'309lm @full
• Lux: (30°) 236lx @5 m full
• Lux: (60°)lx
• CRI: >96
• R9: >82
• TLCI: >97
• TM30 Rf: >94
• TM30 Rg: 100
• Source life expectancy: > 50.000 hrs (L70B10 @Ta 25° C / 77° F)

OPTICS

• Beam angle: 60°
• Field angle: 80°
• Lens type: parabolic reflector in combination with HD fresnel lens
• Additional optics: 30° (inc) - 15° (opt)

DYNAMIC EFFECTS

• Static mode: selection of static colour
• Manual mode: manual adjustment of dimmer and strobe
• Auto mode: built-in programs with execution speed adjustment

BODY

• Body: sturdy die-cast aluminium body
• Body colour: black

CONTROL

• Protocols: DMX512
• DMX channels: 1 / 2 / 5channel
• Display: Graphic User Interface
• Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
• Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 - 28 Hz, electronic
• Operating temperature: -10° ~ +45°
• LED Control: flicker free operation
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 52W
• Power factor: >0,98

PHYSICAL

• IP rating: 20
• Cooling: passive cooling and fan-free
• Suspension and fixing: double hanging bracket suitable for safe hanging and for floor positioning
• Signal connection: XLR 5p IN/OUT connectors
• Power connection: moulded IP power IN connector
• Dimensions (WxHxD): 166x118x250mm / 6.54''x4.65''x9.84''
• Weight: 1,85kg / 4.08lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM
