PL Smart Bat, 4x8W RGBW, IP33, WiFi-DMX, schwarz
inkl. MwSt. zzgl. Versandkosten
Wenn verfügbar beim Hersteller, Lieferzeit ca. 1-3 Werktage.
* Die aktuelle Lieferzeit kann gerne vorab angefragt werden. Jetzt anfragen.
- Artikel-Nr.: SMARTBATBK
Smart Bat is a wireless light designed to rewrite the rules for battery operated fixtures. Ensuring that high performance and good design all housed in a compact size and price that makes it affordable makes the Smart Bat ideal for every kind of event. It can be remotely controlled through proprietary wireless DMX protocol, the SmartColors app or through the IR controller - making it suitable for every level of user.
Main features:
- Wireless operated: through proprietary wireless DMX protocol or SmartColors app for IOS and Android devices
- Long lasting battery life: 12 h in colour changing mode / 8 h in full
- Available in black or white
- Adjustable foot support for tilt regulation (up to 20°)
TECHNICAL SPECIFICATIONS
LIGHT SOURCE
- Source: 4x8W RGBW LEDs
- Luminous flux: 1'127lm
- Lux: 833lx @3 m full
- Source life expectancy: > 50.000 h
OPTICS
- Beam angle: 13°
- Field angle: 30°
- Lens diameter: 42mm / 1.65''
- Additional optics: 25° and 45° optional
COLOUR SYSTEM
- Colour mixing: RGBW / FC
- White presets: 3.200 K ~ 10.000K
- Colour wheel: virtual colour wheel with macros
DYNAMIC EFFECTS
- Static mode: selection of static colour
- Manual mode: manual adjustment of colour
- Auto mode: built-in programs with execution speed adjustment
BODY
- Tilt angle: ° adjustable foot support for tilt regulation (up to 20°)
- Body: sturdy die-cast aluminium body
- Body colour: black, white finishing available
CONTROL
- Protocols: DMX512
- DMX channels: 4 / 6 / 10channel
- Wireless Control: integrated, proprietary protocol compatible with WIFIBOX, WDBOX
- Display: LED display user interface
- Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
- IR: infrared sensor controlled by remote
- Master/Slave: for synchronised operation of more units linked in a chain
ELECTRONICS
- Dimmer: linear 0 ~ 100% electronic dimmer
- Dimmer curves: 4 selectable dimming modes available
- Strobe / shutter: 1 - 25 Hz, electronic
- Operating temperature: 0° ~ +40°
- LED Control: flicker free operation
ELECTRICAL
- Mains power supply: 100-240V - 50/60Hz
- Max power consumption: 30W
- Max power consumption (at 120V): 31W
BATTERY
- Battery: 24V lithium
- Estimated battery life in colour change mode up to: 12h
- Estimated battery life in full-mode up to: 8h
- Re-charge connection: power cable
- Re-charge time: 5h/max
- Battery status: LED battery status indicator
PHYSICAL
- IP rating: 33
- Cooling: passive cooling and fan-free
- Suspension and fixing: M12 threaded insert for easy clamp installation
- Signal connection: XLR 3p IN/OUT connectors
- Power connection: IEC IN/OUT connectors
- Dimensions (WxHxD): 138x184x145mm / 5.43''x7.24''x5.71''
- Weight: 3,4kg / 7.5lbs
CERTIFICATIONS / APPROVALS
- Certifications / Approvals: CE, UKCA, RCM
