PL Smart BatPlusPack, 6er Set Smart BatPlus, im Lade-Case
inkl. MwSt. zzgl. Versandkosten
Wenn verfügbar beim Hersteller, Lieferzeit ca. 1-3 Werktage.
* Die aktuelle Lieferzeit kann gerne vorab angefragt werden. Jetzt anfragen.
- Artikel-Nr.: SMARTBATPLUSPACK
SMARTBATPLUS is the more-advanced member of the successfull SMARTBAT range offering more advanced features such as WDMX wirelss card, waterproof housing, increased brightness, high definition optics and fast-charge magnetic connector. It's packed in a super-slim compact housing with mirror finishing useful when hiding fixtures from view. The pack includes:6 pcs SMARTBATPLUS1 FLIGHT CASE with integrated battery charger kit1 IR controller1 PowerCON power cable
Main features:
- 4x12W RGBW/FullColor high-power LED delivers 905lm
- Long lasting battery capacity: 12h colour changing / 8h FULL
- Mirror finish to hide the luminaire to audience
- Protection: IP65/IP54, for temporary outdoor use
- Built-in antenna transceiver (2,4 Ghz) by Wireless Solution Sweden
- Fast charge magnetic connector
- Adjustable foot support for tilt regulation (up to 20°)
TECHNICAL SPECIFICATIONS
LIGHT SOURCE
- Source: 4x12W RGBW LEDs
- Luminous flux: 905lm
- Lux: 759lx @5 m full
- Source life expectancy: > 50.000 h
OPTICS
- Beam angle: 11°
- Field angle: 19°
COLOUR SYSTEM
- Colour mixing: RGBW / FC
- White presets: 3.200 K -9.000K
- Colour wheel: virtual colour wheel with macros
- Macros: built-in white presets
DYNAMIC EFFECTS
- Static mode: selection of static colour
- Manual mode: manual adjustment of colour
- Auto mode: built-in programs with execution speed adjustment
BODY
- Tilt angle: 20° adjustable foot support for tilt regulation (up to 20°)
- Body: sturdy die-cast aluminium body
- Body colour: mirror finishing
CONTROL
- Protocols: W-DMX
- DMX channels: 4 / 6 / 10channel
- Wireless Control: included, wireless solution receiver
- Display: black OLED touch display
- Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
- IR: infrared sensor controlled by remote
ELECTRONICS
- Dimmer: linear 0 ~ 100% electronic dimmer
- Dimmer curves: 4 selectable dimming modes available
- Strobe / shutter: 1 - 25 Hz, electronic
- Operating temperature: 0° ~ +40°
- LED Control: flicker free operation
ELECTRICAL
- Mains power supply: 100-240V - 50/60Hz (SBPLUSPOWER charger not included)
BATTERY
- Battery: 16,8V lithium
- Estimated battery life in colour change mode up to: 12h
- Estimated battery life in full-mode up to: 8h
- Re-charge connection: magnetic fast-charge in case
- Re-charge time: 4h/max
- Battery status: shown on display
PHYSICAL
- IP rating: for temporary outdoor use - IP65 (front) - IP54 (bottom)
- Cooling: passive cooling and fan-free
- Suspension and fixing: M12 threaded insert for easy clamp installation
- Data connection: W-DMX receiver
- Dimensions (WxHxD): 138x202x145mm / 5.43''x7.95''x5.71''
- Weight: 3,6kg / 7.94lbs
CERTIFICATIONS / APPROVALS
- Certifications / Approvals: CE, UKCA, RCM
Es sind leider keine Geräte verfügbar.
Es kann vorkommen, dass in unserem Lager noch gebrauchte Geräte vorhanden sind. Fragen Sie gerne über unsere Service-Hotline +49 871 40875521 oder per Email info@lights-whatever.de bei uns nach. Wir helfen Ihnen gerne weiter!
