PL Stark Blade8, 8 x 40W RGWB LED, 3° - 45° Zoom, schwarz

Stark Blade8 is a moving batten light designed to deliver a powerful and zoomable 'blade' of beams. Each of the 40W Osram Ostar RGBW LED pixels are individually controllable and completely consistent with the rest of the Stark family.

Main features:

• 8x40W RGBW LED with massive 3° to 45° zoom range
• Infinite pan and tilt rotation
• Individual pixel control with an on-board generator for precise and fast to create effects

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 8x40W RGBW Osram Ostar LEDs
• CCT: Tunable 2.000 K ~ 10.000
• Lux: (3°) 36'391 lx - (45°) 3'113lx @3 m full
• Source life expectancy: > 50.000 h

OPTICS

• Zoom: 3° - 45° motorised linear zoom
• Lens diameter: square 50x50mm / 0''x1.97''
• Lens type: high-quality glass lens optics

COLOUR SYSTEM

• Colour mixing: RGBW / FC
• White presets: 2.000 K ~ 10.000K
• Colour wheel: virtual colour wheel with macros
• Macros: several pre-built pixel macros with adjustable speed

DYNAMIC EFFECTS

• Pixel patterns: pre-programmed dynamic and static patterns
• FX generator: adjustable foreground/background colour, index, speed, direction
• Static mode: selection of static colour
• Manual mode: manual adjustment of colour

BODY

• Pan angle: 540° / 630° with 360° continuous rotation
• Tilt angle: 360° with 360° continuous rotation
• Pan/Tilt resolution: bit 16-bit
• Feedback: automatic repositioning after accidental movement
• Body: aluminium structure with high-resistance polycarbonate cover
• Body colour: black

CONTROL

• Protocols: DMX512, RDM, Art-Net, W-DMX
• DMX channels: 17 / 27 / 55channel
• Pixel control: pixel2pixel control
• Wireless Control: included, wireless solution receiver
• RDM: RDM for remote monitoring and settings
• Display: LCD high resolution colour display with autoflip
• Firmware upgrade: via menu with internal memory or via USB - DMX interface (UPBOX2) not included
• Hibernation: power safe mode when lost DMX
• Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: selectable dimming modes available
• Strobe / shutter: 1 - 25 Hz, electronic
• Display battery: self-charging battery backup
• Operating temperature: -10° ~ +45°
• LED Control: flicker free operation

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 310W
• Max power consumption (at 120V): 310W

PHYSICAL

• IP rating: 20
• Cooling: combination of heat pipe cooling system and low noise fan
• Suspension and fixing: any position with quick-lock omega brackets
• Signal connection: Amphenol XLR 5p IN/OUT connectors
• Data connection: Art-Net RJ45 IN/OUT
• Power connection: Neutrik powerCON TRUE1 IN connector
• Dimensions (WxHxD): 560x433x206mm / 22.05''x17.05''x8.11''
• Weight: 12kg / 26.46lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM
