PL StudioCob FC, 150W RGB-COB, IP20, chrom-farben

StudioCob FC is a powerful, incredibly versatile and full colour LED PAR. Fusing the old and the new, it pairs a full colour COB LED source with a traditional parabolic reflector to deliver a proper Par replacement with a homogenised output, single shadow and flexible lens options.

Main features:

• 150W full colour COB LED source with HD dimming and an extensive and even colour palette
• Flexible lens options of 15° - 30° - 60°
• Functional barn doors for beam control
• RAL9003 white housing

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 150W COB RGB / FC LED
• Luminous flux: 3'682lm
• Lux: (60°) 428lx @3 m full
• Lux: (30°) 908lx @3 m full
• Source life expectancy: > 30.000 h

OPTICS

• Beam angle: 60°
• Field angle: 80°
• Lens type: parabolic reflector in combination with HD fresnel lens
• Additional optics: 30° (inc) - 15° (opt)

COLOUR SYSTEM

• Colour mixing: RGB / FC
• Colour wheel: virtual colour wheel with macros
• Macros: several pre-built macros with adjustable speed

DYNAMIC EFFECTS

• Static mode: selection of static colour
• Manual mode: manual adjustment of colour
• Auto mode: built-in programs with execution speed adjustment

BODY

• Body: sturdy die-cast aluminium body
• Body colour: black, mirror and white finishing available black

CONTROL

• Protocols: DMX512
• DMX channels: 3 / 5 / 8channel
• Display: Graphic User Interface
• Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
• Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 - 28 Hz, electronic
• Operating temperature: -10° ~ +45°
• LED Control: flicker free operation
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 145W
• Max power consumption (at 120V): 145W
• Output (at 230V): 12 units on a single power line
• Power factor: 0,96

PHYSICAL

• IP rating: 20
• Cooling: active, silent operation
• Suspension and fixing: double hanging bracket suitable for safe hanging and for floor positioning
• Signal connection: XLR 3p + 5p IN/OUT connectors
• Power connection: Neutrik powerCON IN/OUT connectors
• Dimensions (WxHxD): 262x190x371mm / 10.31''x7.48''x14.61''
• Weight: 4,5kg / 9.92lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM
