PL EclGalleryProfile TU, 35W, 3000K, W-DMX, weiß

EclGalleryProfile is a compact LED ellipsoidal luminaire engineered with white LED engine and available in Tungsten, Neutral and Daylight White variants, all featuring exceptional high CRI. The luminaire is designed with a stunning aesthetics and it offers a total control of the light, performing a linear zoom system from 16° to 36°, framing shutters for an accurate focusing of the light, and gobo mounting option for image projections. EclGalleryProfile is fitted with electronic and PSU on board, allowing to be implemented on lighting tracks simply applying a track adapter and the fixture can be easily controlled by wireless. EclGalleryProfile is truly flexible for any commercials, venues, art-galleries and churches.

Main features:

• 35W White LED source in multiple variants: Tungsten, Neutral, Daylight
• 16° to 36° on-board zoom with framing shutter and gobo holder
• Wireless DMX control and optional track adapters for easy implementation

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 35W high-power white LED
• CCT: (TU) 3.200 K - (NW) 4.000 K - (DY) 5.000
• Luminous flux: (16°) (TU) 1'887 lm; (NW) 1'947 lm; (DY) 2'095lm @full
• Luminous flux: (36°) (TU) 2'150 lm; (NW) 2'236 lm; (DY) 2'425 lm @full
• Lux: (16°) (TU) 1'209 lx; (NW) 1'324 lx; (DY) 1'782lx @5 m full
• Lux: (36°) (TU) 371 lx; (NW) 367 lx; (DY) 455lx @5 m full
• CRI: (TU) >90 - (NW) > 89 - (DY) >80
• TLCI: (TU) >92 ; (DY) > 67
• TM30 Rf: (TU) >89 ; (DY) > 80
• TM30 Rg: (TU) >98 ; (DY) >93
• Source life expectancy: > 70.000 hrs (L70B10 @Ta 25° C / 77° F)

OPTICS

• Zoom: 16° - 36° manual
• Lens type: high-quality glass lens optics
• Focus: manual
• Other: accessory gobo holder for images and texture projection

DYNAMIC EFFECTS

• Gobo size: E, outer: 37,3 mm - image: 26 mm - thickness: 1,1 mm
• Manual mode: manual adjustment of dimmer and strobe
• Auto mode: built-in programs with execution speed adjustment

BODY

• Body: sturdy die-cast aluminium body
• Body colour: RAL 9004 or RAL 9003

CONTROL

• Protocols: W-DMX
• DMX channels: 1 / 3channel
• Wireless Control: included, wireless solution receiver
• Display: Graphic User Interface

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 - 30 Hz, electronic
• Operating temperature: -20° C / +45° C (-4° F / +113° F)
• LED Control: flicker free operation

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 42W
• Power factor: > 0,97

PHYSICAL

• IP rating: 30
• Cooling: passive cooling and fan-free
• Data connection: W-DMX
• Power connection: moulded IP power IN connector
• Dimensions (WxHxD): 196x293x378mm / 7.72''x11.54''x14.88''
• Weight: 2,5kg / 5.51lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM
