PL EclMiniProfile TU, 28W, 3000K, schwarz, ohne Optik

EclMiniProfile is a new concept of mini LED ellipsoidal. Demonstrating a stylish design, ease of use, precise optics, sharp image projection and bright even projection - all in a compact housing that is just a quarter of the size of the traditional ellipsoidal fixtures. EclMiniProfile is designed for applications in commercial spaces, museums, restaurants, churches, educational theatres and any other installation where size is an important factor. Available in tungsten and daylight versions, EclMiniProfile performs even field projection with high CRI at any level of brightness and linear dimmer over the entire curve.

Main features:

• Bright and compact LED ellipsoidal with sharp optics and shutters
• Available with warm and cold white high CRI LED sources
• Profile lens options (19° - 26° - 36° - 50°) Wash Zoom lens options (15° to 30° - 25° to 50°)

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 28W CREE LED
• CCT: (TU) 3.000 K - (DY) 5.700
• Luminous flux: (TU) (19°) 563 lm - (26°) 554 lm - (36°) 582 lm - (50°) 552lm @full
• Luminous flux: (DY) (19°) 731 lm - (26°) 729 lm - (36°) 743 lm - (50°) 693 lm @full
• Lux: (TU) (19°) 330 lx - (26°) 180 lx - (36°) 96 lx - (50°) 51lx @5 m full
• Lux: (DY) (19°) 397 lx - (26°) 212 lx - (36°) 107 lx - (50°) 52lx @5 m full
• CRI: (TU) >92; (DY) >80
• TLCI: (TU) >90; (DY) >68
• TM30 Rf: (TU) >90; (DY) >79
• TM30 Rg: (TU) >97; (DY) >97
• Source life expectancy: > 50.000 hrs (L70B10 @Ta 25° C / 77° F)

OPTICS

• Beam angle: optional profile lens 19° / 26° / 36° / 50° (gobo holder included) - wash zoom lens 15°-30°/ 25°-50°
• Lens type: high-quality glass lens optics

DYNAMIC EFFECTS

• Fixed gobos: gobo holder Included in optics
• Gobo size: E, outer: 37,3 mm - image: 24 mm - thickness: 1,1 mm
• Manual mode: manual adjustment of dimmer and strobe

BODY

• Body: sturdy die-cast aluminium body
• Body colour: RAL 9004

ELECTRONICS

• Dimmer: linear 0 ~ 100%, manual knob dimmer
• Operating temperature: -20° C / +45° C (-4° F / +113° F)
• LED Control: flicker free operation

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 22W
• Power factor: >0,47

PHYSICAL

• IP rating: 20
• Cooling: passive cooling and fan-free
• Suspension and fixing: bracket for hanging and positioning
• Power connection: moulded IP power IN connector
• Dimensions (WxHxD): 112x176x226mm / 4.41''x6.93''x8.9''
• Weight: 1kg / 2.2lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM
