PL ArcPod 15Q, 15x10W RGBW, 25°, IP66, grau RAL7012

ArcPod 15Q is a compact exterior wash fixture, featuring high-intensity light despite its small size. The unit is equipped with 15x10W RGBW / FC LEDs, delivering an exceptional output over than 5'900 lumens and a wide gamut of colours and whites. The slim sizing, as well as the wide range of available optics, makes the ArcPod 15Q an incredibly flexible architectural fixture to complement the bigger versions in large outdoor installs as accent light or for smaller-sized projects.

Main features:

• Tilt adjustment and multiple lens options for fine focusing
• 15x10W RGBW / FC LEDs
• Compact form factor and fan-free design

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 15x10W RGBW / FC LEDs
• Luminous flux: (10°) 4'552 lm; (15°) 5'678 lm; (25°) 5'732 lm; (45°) 5'390lm @full
• Lux: (10°) 3'116 lx; (15°) 2'790 lx; (25°) 1'203 lx; (45°) 287lx @5 m full
• Source life expectancy: > 50.000 hrs (L70B10 @Ta 25° C / 77° F)

OPTICS

• Beam angle: 25°
• Field angle: 38°
• Lens diameter: 36mm / 1.42''
• Additional optics: 10° - 15° - 45° (optional) - see available accessories

COLOUR SYSTEM

• Colour mixing: RGBW / FC
• CCT: CCT control through dedicated DMX channel
• White presets: 2.800 K ~ 10.000K
• Colour wheel: virtual colour wheel with presets
• Macros: several pre-built macros with adjustable speed

DYNAMIC EFFECTS

• Static mode: selection of static colour

BODY

• Tilt angle: 0 - 130° with manual regulation
• Body: sturdy die-cast aluminium body
• Body colour: RAL 7012

CONTROL

• Protocols: DMX512, RDM
• DMX channels: 5 / 7 / 10channel
• RDM: RDM for remote monitoring and settings
• Display: user interface through DATAMASTER external coder (not included)
• Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
• Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Strobe / shutter: 1 ~ 30 Hz, electronic
• Operating temperature: -20° C / +45° C (-4° F / +113° F)
• LED Control: flicker free frequency with adjustable PWM
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 155W
• Output (at 230V): 14 units on a single power line
• Power factor: >0,97

PHYSICAL

• IP rating: 66 for outdoor installations
• IK rating: 08
• Cooling: passive cooling and fan-free
• Adaptors: XLR and BARE END 16A adaptors included
• Signal connection: 1,8 m moulded IP signal IN/OUT connectors
• Power connection: 1,8 m moulded IP power IN/OUT connectors
• Dimensions (WxHxD): 307x259x83mm / 12.09''x10.2''x3.27''
• Weight: 6,3kg / 13.89lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM, cTUVus, FCC
