PL ArcPod 48Q, 48x10W RGBW, 15°, IP66, grau RAL7012

ArcPod 48Q is a compact high-power exterior wash light featuring an outstanding brightness of 23'000 lumens. It is equipped with 48x10W RGBW / FC LEDs, delivering a limitless reproduction of colours and whites. ArcPod 48Q is designed slim and fanless, and it's completed by a wide selection of available optics, making the ArcPod 48Q an incredibly flexible and versatile device for any outdoor install.

Main features:

• 48x10W RGBW / FC LEDs delivering 23'000 lumens
• LED emitters controllable in 4 sections
• Compact form factor and fanless

TECHNICAL SPECIFICATIONS

LIGHT SOURCE

• Source: 48x10W RGBW / FC LEDs
• Luminous flux: (10°) 18'421 lm; (15°) 22'977 lm; (25°) 20'741 lm; (45°) 16'408lm @full
• Lux: (10°) 37'370 lx; (15°) 30'888 lx; (25°) 12'884 lx; (45°) 2'739lx @3 m full
• Lux: (10°) 13'453 lx; (15°) 11'120 lx; (25°) 4'638 lx; (45°) 986lx @5 m full
• Source life expectancy: > 50.000 hrs (L70B10 @Ta 25° C / 77° F)

OPTICS

• Beam angle: 15°
• Field angle: 27°
• Additional optics: 10° - 25° - 45° (optional) - see available accessories

COLOUR SYSTEM

• Colour mixing: RGBW / FC
• CCT: CCT control through dedicated DMX channel
• White presets: 2.800 K ~ 10.000K
• Colour wheel: virtual colour wheel with macros
• Macros: several pre-built macros with adjustable speed

DYNAMIC EFFECTS

• FX generator: up to 4 linear controllable sections
• Static mode: selection of static colour

BODY

• Tilt angle: 0 ~ 130° with manual regulation
• Body: sturdy die-cast aluminium body
• Body colour: RAL 7012

CONTROL

• Protocols: DMX512, RDM
• DMX channels: 5 / 7 / 10 / 17 / 22channel
• Pixel control: up to 4 linear controllable sections
• RDM: RDM for remote monitoring and settings
• Display: user interface through DATAMASTER external coder (not included)
• Firmware upgrade: yes, via USB - DMX interface (UPBOX1) not included
• Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 ~ 30 Hz, electronic
• Operating temperature: -20° C / +45° C (-4° F / +113° F)
• LED Control: flicker free operation
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 540W
• Output (at 230V): 4 units on a single power line
• Power factor: 0,95
• Inrush current: 230VAC/27.6A, 100VAC/28.6A

PHYSICAL

• IP rating: 66 for outdoor installations
• IK rating: 08
• Cooling: passive cooling and fan-free
• Adaptors: XLR and BARE END 16A adaptors included
• Signal connection: 1,8 m moulded IP signal IN connectors
• Power connection: 1,8 m moulded IP power IN/OUT connectors
• Dimensions (WxHxD): 584x304x93mm / 22.99''x11.97''x3.66''
• Weight: 14kg / 30.86lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM, cTUVus, FCC
